China Pipe shoe (Rod shoes) NQ IMP Manufacturers, Quotes

Pipe shoe NQ (NO) IMP 3760900724

Used for: wireline drill

Other nameï¼šRod shoes

Send Inquiry

Product Description

Product Name: Pipe shoe NQ (NO) IMP 3760900724

Application: Designed specifically for wireline drill operations.

During opening hole drilling jobs, choosing the right casing shoes is critical for success. We offer a comprehensive selection of reliable casing shoes and rod shoes designed to make the hole-opening process smoother and more efficient. Our range includes quality-proven standard casing shoes and heavy-duty options, ensuring that users can reach bedrock with minimal equipment loss.

Technical Specifications

The choice of a casing shoe is determined primarily by soil properties and the thickness of the cover layer. A full range of sizes is available to meet various geological conditions.

Description	Outside Diameter		Inside Diameter
Model	Inches	mm	Inches	mm
BQ	2.345	59.56	1.78	45.21
NQ	2.965	75.31	2.37	60.20
HQ	3.615	91.82	2.992	76.00
PQ	4.750	120.66	3.985	101.22

Production Capabilities & Customization

Manufacturing capabilities extend to a wide variety of standard geological core drill pipes and specialized tools. The production line includes:

✓

Impregnated and Surface Set Diamond Core Bits

✓

PDC Diamond Core Bits and Non-coring Bits

✓

Reaming Shells (Impregnated and Natural Diamond)

✓

Hydraulic Holders, Pipe Twisters, and Underground Drilling Rigs

With strong product development capabilities, solutions can be customized according to specific customer requirements and geological challenges.

Frequently Asked Questions

What is the primary use of a Pipe Shoe NQ?

The Pipe Shoe NQ is primarily used for wireline drilling operations to facilitate smoother hole-opening and ensure the casing string can effectively reach the bedrock through various soil layers.

How do I choose the right casing shoe size?

The choice depends on the soil properties, the thickness of the cover layer, and the specific diameter of your drill rods. Standard sizes include BQ, NQ, HQ, and PQ.

Are there different types of casing shoes available?

Yes, we provide both standard casing shoes and heavy-duty casing shoes to handle different levels of geological resistance and abrasive conditions.

What diamond bit options are compatible with these tools?

Our tools are compatible with a wide range of bits, including impregnated diamond bits, surface set diamond bits, and PDC bits, depending on the hardness of the formation.

Can drilling tools be customized?

Yes, there are strong development capabilities to provide customized drilling tools and rigs based on special technical requirements or unique site conditions.

What are the dimensions for an HQ rod shoe?

An HQ rod shoe typically has an outside diameter of 3.615 inches (91.82 mm) and an inside diameter of 2.992 inches (76 mm).
