China T45 Speed Rods Extension Speed Rod Drilling Bench Rock Drill Rod Underground Mining Factories, Pricelist

Customization:	Available
Length:	0.5m-6.4m
Usage:	Rock Drilling

ℹ️

Basic Information

Model NO.

T45 Speed rods

Material

Carbon Steel

Thread

R22, R25, R28, R32, R38, T38, T45, T51, St58, T60

Machine Type

Drilling Tools

Color

Red, Black, Yellow, White

Material Quality

23crni3mo D6a

Connection Mode

Speed Drill Rod

Package Size

30.00cm * 30.00cm * 30.00cm

Gross Weight

5.000kg

Production Capacity

500,000 PCS/Month

🛠️

Product Description

Bench and production drilling tools include rods, shank adapters, couplings and bits. We provide a comprehensive range of 7 threads: R3212, R32, HL38, T38, T45, T51, T60, ST58, and ST68. These are perfectly compatible with button bits, cross bits, and reaming products.

Drifter Rod: Also known as tunneling steels or tunneling rods. Available in round and hexagon shapes. Hexagon drill steel is primarily used for tunneling and drifting applications. These rods are more rigid and heavier, allowing for more efficient energy transfer and increased flushing capacity.

Extension Rod: Also referred to as extension drill steel or M/F rod (Speed rod).

Hexagon Rods: Highly rigid and heavy, designed for superior energy transfer and flushing.
Round Rods: Generally lighter than hexagonal rods, typically used in standard extension drilling applications.

Technical Specifications:

Steel Grade: Male-Male Rod, MF Rod, 23CrNi3Mo
Rod Sizes: Diameter 32mm, 39mm, 46mm, 52mm, etc.
Length Options: 0.4m - 6m
Packaging: Secure wooden cases or bundles.

📊

Specifications Table

R32 - R32 - Rd 32 (1-1/4" ROPE THREAD) - Carburized
Type	D (mm)	Length (mm)	Length (ft)	Left Thread	Right Thread
Standard	RD 32	610	2'	R32	R32
Standard	RD 32	915	3'	R32	R32
Standard	RD 32	1220	4'	R32	R32
Standard	RD 32	1830	6'	R32	R32
Standard	RD 32	3050	10'	R32	R32
Standard	RD 32	3660	12'	R32	R32

MF-Rod R32 - R32 - Rd 32 (1-1/4" ROPE THREAD) - Carburized
Type	D (mm)	Length (mm)	Length (ft)	Left Thread	Right Thread
MF-Rod	RD 32	915	3'	R32F	R32
MF-Rod	RD 32	1220	4'	R32F	R32
MF-Rod	RD 32	1525	5'	R32F	R32
MF-Rod	RD 32	1830	6'	R32F	R32
MF-Rod	RD 32	3050	10'	R32F	R32
MF-Rod	RD 32	4270	14'	R32F	R32

❓

Frequently Asked Questions

What materials are used for the T45 speed rods?

The rods are manufactured using high-quality Carbon Steel and 23CrNi3Mo (D6A) grade steel for maximum durability and energy transfer.

What is the difference between Hexagonal and Round extension rods?

Hexagonal rods are more rigid and heavier, providing better energy efficiency and flushing. Round rods are lighter and generally used in standard extension drilling applications.

What thread types are available for these drilling tools?

We offer a wide variety of threads including R22, R25, R28, R32, R38, T38, T45, T51, ST58, and T60 to fit different machine requirements.

What are the typical applications for Drifter Rods?

Drifter rods, also known as tunneling steels, are primarily used for tunneling and drifting drilling applications where high energy transfer is required.

Can these rods be used with reaming products?

Yes, our bench and production drilling tools are designed to be fully compatible with button bits, cross bits, and various reaming products.

What is the available length range for the extension rods?

Our extension rods are available in various lengths ranging from 0.4 meters up to 6 meters to suit different drilling depths.
