China Tapered drill bit Factory, Quotes

Taper button bit as small hole bit is different with thread button bit as long hole bit to use taper match with bit with rod to be used for air leg or hand held jack hammer driller in quarrying,and mining. Description :

(1)Connect shank Size: Î¦19, Î¦22, Î¦25 at most

(2)Bit Diameter:Diameter 32mm,34mm,36mm, 38mm,40mm

(3)Tapered connection: 6 degree, 7 degree, 11 degree, 12 degree etc.

(4)Materialï¸°Alloy Steel Bar 45CrNiMoV, Tungsten Carbide Tips YK05 or T6.

(5)Button Shapeï¸° Ballistic Face Typeï¸° Flat Face; Bit Bodyï¸°Standard

(6)Qty of button: 5,7, 8 pcs

(7)main market: India, Saudi, Chile, South Africa,stone country consume too much

Send Inquiry

Product Description

Tapered button bit as small hole bit is different with thread button bit as long hole bit to use taper match with bit with rod to be used for air leg or hand held jack hammer driller in quarrying and mining.

⚙️ Technical Description

Connect Shank Size Φ19, Φ22, Φ25 at most

Bit Diameter 32mm, 34mm, 36mm, 38mm, 40mm

Tapered Connection 6 degree, 7 degree, 11 degree, 12 degree etc.

Material Alloy Steel Bar 45CrNiMoV, Tungsten Carbide Tips YK05 or T6

Design Ballistic Button Shape, Flat Face, Standard Bit Body

Quantity of Buttons 5, 7, 8 pcs

💎 Quality Commitment

Following the spirit of "Quality, Efficiency, Innovation and Integrity," the goal is to create significant value for buyers through abundant resources, highly developed machinery, and experienced professional providers. Adhering to the "superior quality, reputable, the user first" principle wholeheartedly, we welcome global partners to work together and create a brilliant future.

Frequently Asked Questions

What is the difference between tapered and thread button bits?

Tapered button bits are primarily used as small hole bits with a taper match for air leg or hand-held jack hammer drills, whereas thread button bits are typically used for long hole drilling.

What materials are used in these drill bits?

The bits are manufactured using high-quality Alloy Steel Bar 45CrNiMoV and feature Tungsten Carbide Tips (YK05 or T6) for maximum durability.

Which taper degrees are available for connection?

We offer a variety of standard tapered connections, including 6 degree, 7 degree, 11 degree, and 12 degree options to suit different drilling equipment.

In which industries are these tapered bits most commonly used?

These bits are essential tools in quarrying and mining industries, particularly in regions with high stone consumption like India, Saudi Arabia, Chile, and South Africa.

How many carbide buttons are on each bit?

Depending on the diameter and specific requirements, the bits typically come with 5, 7, or 8 ballistic-shaped buttons.

What are the available bit diameters?

The standard diameters available range from 32mm to 40mm, including 34mm, 36mm, and 38mm sizes.
