Product Details

Customization:	Available
After-sales Service:	Repair or Replacement
Warranty:	6 Months

Send Inquiry

Product Description

🔹 Basic Specifications

Model NO.

CIR150

Certification

CE, ISO 9001:2000, ISO 9001:2008

Standard

AISI, GB

Surface Treatment

Spray-Paint

Material

Carbon Steel

Machine Type

Drilling Tools

Length

904mm

Outside Diameter

136mm

Weight

70kg

Working Pressure

5-10bar

Origin

China

Production Capacity

500,000 PCS/Month

⚙️ Product Overview

Because of economy and powerful drilling capacity, the down the hole hammer has become an advanced drilling tool for the drilling and mining industries. These hammers and drill bits are designed to work in perfect unison, delivering high penetration rates, long service life, and low operational costs.

🚀 Fast Penetration

Delivers maximum energy to the drilling bit with high speed and low air consumption due to a specialized inner structure based on modern rock drilling theory.

🛠️ Durable Construction

Adaptation of high-quality alloy steel materials and advanced processing technology ensures smooth performance and extended service life.

🔧 Easy Maintenance

Simple, reliable internal structure allows for easy assembly and disassembly, significantly reducing maintenance downtime.

📊 Technical Data - DTH Hammers

Type	Model	Length (mm)	Weight (kg)	External Dia. (mm)	Hole Range (mm)
3.5 inch	DHD3.5	930	25	Φ82	Φ90-110
4 inch	DHD340	1030	39	Φ99	Φ110-135
	SD4	1084	40.5	Φ99
	QL4	1097	41	Φ99
	Mission40	1005	40	Φ99
5 inch	DHD350	1214	76.5	Φ125	Φ135-155
	SD5	1175	72.5	Φ125
	QL5	1147	73	Φ125
	Mission50	1110	68.5	Φ125
6 inch	DHD360	1248	100	Φ142	Φ155-190
	SD6	1261	100	Φ142
	QL6	1212	95	Φ146
	Mission60	1161	90	Φ146

📉 Low Air Pressure Hammers

Item	Length (mm)	Outside Dia (mm)	Weight (KG)	Bit Dia (mm)	Pressure (Bar)	Bit Shank
CIR-50	628	44	5	50	4-10	CIR50
CIR-60	777	53	7.5	60	4-10	CIR60
CIR-65	745	61	13	65	4-10	CIR65
CIR-76	811	66	13.5	76	4-10	CIR76

📦 Packaging & Delivery

Package Type: Wooden Case
Package Size: 30.00cm * 30.00cm * 30.00cm
Gross Weight: 5.000kg

Monthly Productivity: 2000 PCS
Suitable for: Water well drilling, Mining, Bench drilling, Civil Engineering.

Frequently Asked Questions (FAQ)

1. What applications are these DTH hammers suitable for? They are ideal for water well drilling, mining, mineral exploration, oil well drilling, and various civil engineering projects.

2. What are the key advantages of using the HD series DTH hammer? The main benefits include fast drilling speeds, low air consumption, long service life, and an easy-to-maintain internal structure.

3. Are your DTH hammers compatible with different bit shanks? Yes, our hammers are interchangeable with various DTH bits including DHD, SD, QL, Mission, and CIR series shanks.

4. How is the durability of the hammer ensured? We use high-quality alloy steel and advanced processing technologies to ensure all components can withstand high-pressure drilling environments.

5. Do you offer both low and high-pressure hammers? Yes, we provide a full range of hammers suitable for both low air pressure and high-pressure drilling rigs.

6. How is the product typically packaged for shipping? All hammers and components are securely packed in robust wooden cases to ensure safety during international transit.
