Bench and production drilling tools include rods, shank adapters, couplings and bits. We have mainly 7 threads: R3212, R32, HL38, T38, T45, T51, T60, ST58 and ST68. They can be used with button bits, cross bits and reaming products.
| R32 - R32 - Rd 32 | 1-1/4" ROPE THREAD (32mm) Carburized | ||||
|---|---|---|---|---|
| D | LENGTH (L) | THREAD | ||
| mm | FT | Left | Right | |
| RD 32 | 610 | 2' | R32 | R32 |
| RD 32 | 915 | 3' | R32 | R32 |
| RD 32 | 1000 | 3' 3" | R32 | R32 |
| RD 32 | 1220 | 4' | R32 | R32 |
| RD 32 | 1525 | 5' | R32 | R32 |
| RD 32 | 1830 | 6' | R32 | R32 |
| RD 32 | 2435 | 8' | R32 | R32 |
| RD 32 | 3050 | 10' | R32 | R32 |
| RD 32 | 3660 | 12' | R32 | R32 |
| RD 32 | 4265 | 14' | R32 | R32 |
| RD 32 | 4915 | 16' 1-1/2" | R32 | R32 |
| RD 32 | 5490 | 18' | R32 | R32 |
| MF-Rod R32 - R32 - Rd 32 | 1-1/4" ROPE THREAD (32mm) Carburized | ||||
|---|---|---|---|---|
| D | LENGTH (L) | THREAD | ||
| mm | FT | Left (R32F) | Right (R32) | |
| RD 32 | 915 | 3' | R32F | R32 |
| RD 32 | 1220 | 4' | R32F | R32 |
| RD 32 | 1830 | 6' | R32F | R32 |
| RD 32 | 3050 | 10' | R32F | R32 |
| RD 32 | 3660 | 12' | R32F | R32 |
| RD 32 | 4270 | 14' | R32F | R32 |
| RD 32 | 6300 | 20' 8" | R32F | R32 |
We offer a wide range of threads including R3212, R32, HL38, T38, T45, T51, T60, ST58, and ST68 to suit various drilling requirements.
The rods are manufactured using high-quality Carbon Steel and 23CrNi3Mo alloy steel, processed through forging and carburized surface treatment for maximum durability.
Our standard lengths range from 0.4 meters up to 6 meters, covering various bench and production drilling needs.
Products are typically packed in sturdy wooden cases or bundles to ensure they are protected during transit and delivery.
Our products are manufactured under strict quality control and comply with ISO 9001:2000 and ISO 9001:2008 standards.
We have a high productivity rate of approximately 20,000 MT per month, with a specific capacity of 500,000 PCS per month for standard items.
