Shank adapter for Sandvik HLX5 drill rig

Send Inquiry

Product Description

✓

Premium Manufacturing

Shank adapters are carburized, CNC manufactured, and made from premium steel to ensure superior toughness and anti-fatigue strength.

✓

Demanding Conditions

Designed to meet the most demanding drilling conditions and withstand the high impact power of modern rock drills.

Rock drilling tools include shank adapters for most models of current prevailing rock drill machines. These components are specifically designed to transmit rotation torque, feed force, impact energy, and flushing medium to the drill string, including extension drill rods and drifting drill steels.

Application Specific Designs

Male Shank Adapters

Generally better suited for drifting, tunneling, and extension applications where high bending stresses are present.

Female Shank Adapters

Used when drilling space is limited and total feed length is critical, such as in underground roof bolting.

Product Specifications

A wide range of approximately 300 different shank adapters is available, suitable for various series drifters including popular industry models.

Technical Data: Shank adapter for Sandvik HLx5 HLX5T HFX 5T RDX5 Drill Rig

SANDVIK - HLX 5, HLX 5 T, HFX 5 T RDX5 (10 SPLINES)
THREAD	OVERALL LENGTH (L)		FRONT END DIA.		Product No.
THREAD	mm	In.	mm	In.	Ref 1	Ref 2
R32	500	19.69	45	1.75	7803-7585-01	-
R38	500	19.69	45	1.75	7804-7585-01	90516173
SR38	500	19.69	45	1.75	-	90516177
T38	500	19.69	45	1.75	7304-7585-01	90516198
T45	500	19.69	45	1.75	-	90003672
R32	575	22.64	45	1.75	7803-7586-01	-
T35	575	22.64	45	1.75	7307-7586-01	-
SR38	575	22.64	45	1.75	-	90516178
T38	575	22.64	45	1.75	7304-7586-01	90516199
T45	575	22.64	45	1.75	7305-7586-01	90516144
T38	600	23.62	45	1.75	-	-
T45	600	23.62	45	1.75	-	-

Frequently Asked Questions

What materials are used for the shank adapters?

The shank adapters are manufactured using premium selected steel and undergo a cauterizing/carburizing hardening process to ensure maximum durability.

How does the manufacturing process ensure quality?

All adapters are CNC manufactured for high precision, providing superior toughness and anti-fatigue strength to handle modern rock drill impact power.

What is the primary function of a shank adapter?

Its main task is to efficiently transmit rotation torque, feed force, impact energy, and flushing medium from the machine to the drill string.

When should I choose a male vs. a female shank adapter?

Male adapters are ideal for drifting and tunneling with high bending stress. Female adapters are preferred when space is limited, such as in underground roof bolting.

Are these adapters compatible with different drill rig brands?

Yes, there are approximately 300 different models available suitable for various drifters, including Sandvik, Atlas Copco, and Tamrock series.

What specific Sandvik models do these adapters fit?

They are specifically designed to fit Sandvik HLX 5, HLX 5 T, HFX 5 T, and RDX5 series with 10 splines.
